Click to zoom MPZ5F0F Dome Camera

MPZ5F0F

Name: MPZ5F0F
Brand: MACTRA
SKU: MPZ5F0F

5MP Wide-Angle Fixed · Dome Camera · 60m IR

5MP Ultra-HD Network Dome Camera with wide-angle fixed lens, smart motion detection, and 60m IR range for demanding commercial and enterprise environments.

Download Datasheet Sales Enquiry

1-Year Warranty STQC Compliant Made in India

5MP Resolution 2592 × 1944 px

Night Vision Hybrid IR up to 60m

AI Analytics Smart Motion Detection

Weatherproof IP66, IP67, NEMA 4X

PoE+ IEEE 802.3af Type 1

Full Specs

Technical Specifications

Complete reference for the MPZ5F0F. Pick a section to jump to it — the panel scrolls on its own.

Camera

Sensor Resolution	5MP
Sensor Type	CMOS
Sensor Size	1/2.78"
Minimum Illumination	Color = 0.01 lux, Monochrome = 0 lux
Day/Night	Auto, Manual Day Mode / Night Mode
Camera Adjustable Angle	Pan 0°–355°, Tilt 0°–75°, Rotate 0°–355°

Lens

Focal Length	2.8 mm
HFOV	104.3°
VFOV	57.9°
DFOV	121.8°
Lens Mount	M12x0.5
Focus	Fixed
Aperture	F1.6
Iris Type	Fixed

Illuminator

LED Type	Hybrid LEDs (IR LED + White LED)
No. of LEDs	3 Hybrid LEDs
IR Distance	Up to 60 meters
IR Wavelength	~850 nm
IR & White Light Control	Auto, Manual (ON/OFF/Adjustable)

Audio & Video

Stream Capability	Triple Stream
Main Stream	5MP (2592×1944) / 4MP/2K (2560×1440) / 2MP/FHD (1920×1080) / 1MP/HD (1280×720) @1–25/30fps
Sub Stream	1MP/HD (1280×720) / D1/480P (720×480) / VGA/360P (640×360) @1–25/30fps
Preview Stream	1MP/HD (1280×720) / D1/480P (720×480) / VGA/360P (640×360) @1–25/30fps
Video Standards	PAL/NTSC
Video Compression	H.265, H.264, MJPEG
Video Bitrate Type	CBR
Video Bitrate	128 kbps–16 Mbps
Region of Interest (ROI)	Supported
Audio Bit Rate	64 Kbps
Audio Codec	G.711/PCM
OSD	Supported


Image Settings	Brightness, Contrast, Saturation, Hue, Sharpness, Lens Distortion Correction
Wide Dynamic Range	~120 dB
S/N Ratio	50 dB
Noise Reduction	2D/3D NR
Image Rotation	Mirror, Flip, Rotation (0°, 90°, 180°, 270°)

Communication

Ethernet Interface	1 × RJ45 10M/100M Self-Adaptive Ethernet Port
Power Reset Key	Available
Built-in Microphone	Available
Relay	2 × Channel
RS485	1 × Channel
GPIO	4 × GPIO On Pigtail
SD Card	Up to 512GB

Networks

Supported Protocols	TCP/IP, HTTP, HTTPS, DHCP, SRTP/RTSPS, RTP/RTSP, SMTP, NTP, TLS/SSL, FTP/FTPS, ICMP, IGMP, ARP, UDP, 802.1x, SNMP
Interoperability	ONVIF Profile S/G/T
Max. Users Access	10 Users
Web Support	Edge, Chrome, Mozilla

Analytics

Alarm Event	SD Card Connect/Disconnect, SD Card Full, Wrong Login, Box Tamper Detection
Recording Type	General, Event, Alarm, Configurable Recording Streams
Recording Storage	SD Card, FTP/FTPS

AI Analytics

AI Enabled	Motion Detection, Visual Tamper Detection
Edge AI	Line Crossing Detection, People Counting

Security

Secure Boot	Supported
Security	User account and password protection, HTTPS, TLS 1.3/1.2, SSH/Telnet Disabled
HTTPS Streaming	Using TLS 1.3/1.2
Network Authentication	Yes, 802.1x Network authentication
Firmware Upgrade	Supported
Antirollback Firmware	Supported
Web Login Protection	Supported
SD Card Encryption	Supported
Reader Interface	Secure Channel Supported

Hardware

Power Supply	12V(DC); 802.3af (PoE)
Power Consumption	~13W

Mechanical

Body Material	Metal Casting (Die Casting Aluminium with Powder Coating), PC
Product Dimension	126 × 105 mm (Φ × H)
Product Weight	~750 gms
Body Color	Infinity White

Compliance

Humidity	Less than 95% RH (Non-Condensing)
Operating Temperature	-20°C to 70°C
Storage Temperature	-30°C to 60°C
Ingress Protection	IP66, IP67, NEMA 4X
Impact Resistance	IK10

Certificates

Emissions	FCC PART 15
Certificates	STQC, BIS, CE
RoHS	Yes
REACH	Yes
Country of Origin	India
NDAA	Compliant
Safety	UL 62368-1, EN 62368-1, IEC 62368-1
